Connect the hardware

  1. The XBee Smart Modem should already be plugged into the development board. For more information about development boards, see Development boards.
  1. Connect the antennas to the XBee Smart Modem. Align the U.FL connectors carefully, then firmly press straight down to seat the connector. You should hear a snap when the antenna attaches correctly. Caution should be used when connecting or removing the U.FL. Digi recommends using a U.FL removal tool when removing the U.FL, such as U.FL-LP-N-2.
  1. Connect the USB-C cable from a PC to the USB port on the development board. The computer searches for a driver, which can take a few minutes to install.

    Note The USB-C cable must be plugged into a port that will supply a minimum of 1 Amp of current for the device to work as expected.
